סוויץ´ 5 פורטים ג´יגה, פלסטיק
• Support 1000M speed rate,MDI/MDIX
• Support IEEE802.3x Flow control and back pressure control
• Each port has the complete LED Indicator light
• Support IEEE802.1d Spanning Tree
• Each port supports wire-speed switching ,64~1518 frame length can reach the wire speed
• Support high performance QoS function on each port
• Support multicast to avoid network congestion
• Support 5-16V voltage inpu
|
Product |
Gigabit Ethernet Switch-5 Ports, Plastic |
|
|
Model |
18290 |
|
|
Standards |
IEEE802.3 10Base-T IEEE802.3u 100Base-TX/FX |
IEEE802.3x Flow control IEEE802.1p QoS IEEE802.1d Spanning Tree |
|
Certifications |
CCC, CE |
|
|
Ethernet Port |
Connector: RJ45 Data Rate: 10/100/1000M Distance: 100m UTP Type: UTP-5E or higher level |
|
|
Performance |
Processing Type: Store and Forward Transmission Mode: half/full-duplex with auto-negotiation function MAC Table Size: 1K Buffer Space: 448K Back bandwidth: 10G Time Delay: <150cm |
|
|
Power |
Power type: external power supply Input Voltage: AC100V~240V 50/60Hz Connector: DC Socket Working Voltage: 5V Power Consumption: 1.8W~4W |
|
|
Environment |
Storage Temperature: -40~70C Operating Temperature: -10~55C Relative Humidity: 5-90% ( no condensation) |
|
|
Physical Characteristics |
Dimension: 100×52×28mm Weight: 0.30kg Color: Metal, Black |
|
